Product Description
GSC Power-Division High Pressure Ovate Conical Spring kit with Ti Retainer and Spring seats for the Ford Gen 3 Coyote 5.0 For the F150 and Mustang. Also fits Gen 4 Mustang and F150 Coyote as well.
- Installed: 97 lbs @ 1.621"
- Open: 295 lbs @ 1.020"
*Flip phone to landscape to see full table!*
| GSC5012 High Pressure Ovate Conical Valve Spring Kit with Ti Retainer and seats for Gen 3 and Gen 4 (F150 & Mustang). | |||||
| Setup | Coil Bind (in) | Install Height (in) | Seat Pressure (lbs) | Open Pressure | Maximum Valve Lift (in) |
| Ovate Conical | 0.960 | 1.621 | 97 | 295 lbs @ 1.020 | 0.600 |
