| Product Market |
Modern Muscle |
|---|---|
| Bore Diameter |
3.572 IN |
| Compression Height |
1.220 IN |
| Piston Volume |
-5.00 CC |
| Piston Average Weight |
Call |
| Ring Set Part Number |
09403572 |
| Top Compression Ring Thickness |
1.20 MM |
| Second Compression Ring Thickness |
1.50 MM |
| Oil Ring Thickness |
3.00 MM |
| Ring Set Included |
Yes |
| Oil Rail Support Included |
No |
| Wrist Pin Part Number |
H8662500225C |
| Wrist Pin Outside Diameter |
0.866 IN |
| Wrist Pin Length |
2.500 IN |
| Wrist Pin Retainer Part Number |
015113-16 |
| Wrist Pin Retainer Included |
Yes |
| Piston Series |
3V Mod Motor 4.6L |
| Product Type |
Engine Piston Kit |
| Stroke |
3.543 IN |
| Rod Length |
5.933 IN |
| Ring Set Thickness |
1.20 MM x 1.50 MM x 3.00 MM |
| Piston Quantity |
8 |
| Forging Type |
Full Round |
| Cylinder Quantity |
8 |
| VP Intake Depth |
0.000 IN |
| VP Exhaust Depth |
0.075 IN |
| Add-On |
015113-16|09403572|H8662500225C |
| Compression Ratio |
9.60 |
| Wrist Pin Dimensions |
0.866 x 2.500 |
Product Description
The muscle car era is back with a horsepower-fueled vengeance and Diamond has late-model muscle builders covered with a huge selection of performance pistons. Whether you’re building an LS, LT, Modular/Coyote, or a third generation Hemi, Diamond has the pistons you need to get the job done right. Pistons are available for builders seeking more cubic inches, higher compression, or nitrous/boost ready performance, and all of Diamonds Modern Muscle pistons are forged and machined 100% in the USA, utilize extremely strong 2618 aluminum and incorporate premium Trend Performance wrist pins.
